X.e Series Industrial Gear Units

SEW-EURODRIVE X.e industrial gear units are the large helical and bevel-helical range. They cover 7.2 to 500 kNm with ratios from 6.3 to 450. The modular design offers one-piece or split housings and universal mounting positions.

Motor adapters, backstops and a choice of shaft and sealing systems are available, along with ATEX versions. Abtaz supplies X.e units for cranes and hoists, conveyor belts, bucket elevators, mixers, crushers and bulk handling. Send us the duty data for a selection.

X.E SERIES INDUSTRIAL GEAR UNIT RANGE

  • X.e helical gear units

    In-line construction within the 23 graduated sizes of Generation X.e.

    The helical construction takes the drive straight through, for installations where input and output shafts lie on the same axis. It shares the Generation X.e range of 7.2 to 500 kNm and ratios from 6.3 to 450, with one-piece or split housings and the common set of motor adapters, backstops, sealing and shaft systems.

  • X.e bevel-helical gear units

    Right-angle construction within the same Generation X.e range.

    The bevel-helical construction turns the drive through a right angle, which suits conveyor heads, bucket elevators and mixers where the motor cannot sit in line with the driven shaft. Torque range, ratio range, housing options and modular features match the helical units.

OTHER SEW-EURODRIVE INDUSTRIAL GEARBOX PRODUCTS

REQUEST A QUOTE

Not sure which solution best fits your application? Our engineers are available to review your requirements and help you select the most suitable products and materials for your project.

Request a Quote

quotation form

This field is required.
This field is required.
This field is required.
SEW-EURODRIVE X..e Series Catalogue

SEW-EURODRIVE X..e Series Catalogue

SEW-EURODRIVE Industrial Gear Units, X..e Series helical and bevel-helical gear units, torque classes 7.2 to 500 kNm. Edition 07/2023 (SEW document 30593506/EN).

DOWNLOAD CATALOGUE
